Robot Placement Series
VG8RTFW-300 Industrial robot winding machine is a suitable machine for manufacturing complex shape products. It can manufacture many kinds of non equal diameter revolving bodies whose section may be ladder or rectangle or oval if we use different winding software. It can also manufacture cone and elbow. In additional the machine can be used for prepreg tape winding with dry winding method.

Main specification:
1. Winding diameter 300mm(Max)
2. Spindle revolution 60rpm(Max)
3. Horizontal axial stroke 3000mm(Max)
4. Radial stroke 600mm(Max)
5. Vertical stroke 600mm(Max)
6. Vertical horizontal axis rotation range ±90°
7. Rotating range around the radial axis ±90°
8. Rotating range around the vertical horizontal axis ±90°
8. Velocity feed band 1000mm/s(Max)
9. Fit winding mode wet、dry(prepreg tape winding)
