Robot Placement Series
VG16RTFW-500 robot winding machine is a suitable machine for manufacturing the complex shape products. The machine can be used to manufacture the products with different reinforcement materials. The machine can also complete auto winding when put auto cut off/placement fibre device to it. The machine can manufacture several shape such as cylinder and elbow and special cone and so on.

Main specification:
1. Winding diameter 500mm (Max)
2. Spindle revolution 40rpm(Max)
3. Horizontal axial stroke 9000mm(Max)
4. Horizontal radial stroke 1000mm(Max)
5. Vertical horizontal stroke 1000mm(Max)
6. Rotating range around the vertical horizontal axis ±90°
7. Velocity feed band 600mm/s(Max)
8. Band width 40mm(Max)
9. Follow-up creel stroke 9000mm(Max)
