Robot Placement Series

The core of this machine is a automated tape laying head that has been developed of self, and the 8-axis industrial robot is used as a assistant motion unit. This machine can been used for irregular prepreg tape placement with any positive and negative curvature.

Main specification:
1. Placement size 150015001500mm(Max)
2. Band width 120mm(Max)
3. Placement accuracy 0.2mm
4. Placement velocity 500mm/s(Max)
5. Kinds of prepreg tape can be used carbon fibre/glass fibre



VG8RFP Robot Tape Placement Machine
Robot Fibre Placement Machine
