VG3FW-3000

    VG3FW-3000 computer-controlled winding machine with three axes is specially designed to manufacture vessels with large diameter and small polar. It can not only manufacture vessels with small angle, but also manufacture FPR pipes with large diameter. So it is a desirable multi-functional machine to produce large FRP products.
Main specification:
Winding diameter 3000mm (Max)
Winding length 12000mm (Max)
Band width 200mm (Max)
Position precision < 1mm
Radial feed 1500mm (Max)
Winding angle 5～90o
